Advantech New Fanless Embedded System
Advantech is glad to announce the
ARK-6322, a fanless, embedded, box PC with quad core processor, rich I/O ports, and flexible customization. It is powered by an Intel Celeron Quad Core J1900 2.0GHz SoC delivering performance increases of 150% compared to the previous Atom platforms, and with more than three times better graphics performance. ARK-6322 supports full I/O ports including six serial ports, eight USB ports, dual LANs, one VGA, and one display port. The storage options include mSATA and a hard drive bay which is compatible with a 3.5 inch or 2.5 inch HDD. For the expansion capability, ARK-6322 provides two mini PCIe slots for Wi-Fi, mobile, GPS and mSATA. It also reserves front panel space for iDoor modules, a series of mini PCIe cards with functional connectors such as isolated/non-isolated COM ports, CANBus, LAN, digital I/O and printer port in order to fulfill various custom requests. ARK-6322 carries worldwide EMC & Safety Certifications (CE/ FCC/ UL/ CCC/ CB/ BSMI). It is a convenient yet reliable custom system focused on machine automation, industrial plants, and the IoT market with longevity till Y2020.
Excellent Performance with Dual Display, Dual Storage and Full I/O Ports
ARK-6322 is designed using an Intel Celeron J1900 Quad Core 2.0 GHz processor with burst speed up to 2.41 GHz. It supports dual, independent display VGA and display port. The Intel Gen 7 graphics engine features include DirectX11, openGL3.2, openCL 1.2, hardware decode H.264, MPEG2, MVC, VC-1, WMV9, MJPEG, and VP8 support. ARK-6322 also provides for massive data storage. Users can install their operating system on the mSATA and have the 3.5/2.5 inch HDD for data which helps save on storage cost and maintenance. Moreover, ARK-6322 can not only do basic data transmission but can also analyze and process information which efficiently accelerates decision making. ARK-6322 supports operating temperatures 0~40 °C with a 2.5” HDD or 0~45 °C with a 3.5” HDD, and 0~50 °C with SSD/mSATA. Our outstanding mechanical design provides a reliable solution for low maintenance and passes 0.5G vibration and 10G shock testing, even with HDD operating. We supply wall, VESA, and DIN-rail mounting kits for a variety of application environments. With competitive pricing and plenty of features, ARK-6322 is an ideal industrial PC where excellent performance is combined with multiple ports and custom support.
High Flexibility with Reserved iDoor Module for Diverse Applications
ARK-6322 provides high flexibility with reserved iDoor space on the front bezel. Custom requirements are easily satisfied with mini PCIe modules such as isolated or non-isolated COM ports, CANBus, parallel LPT, DIO and LAN port, via a series of optional MOS modules for ARK Series. MOS modules feature extended functional I/O ports that expand the system to serve diverse applications. ARK-6322 offers over ten different SKUs including the MOS-2220-Z1101E for up to a total of 3 GigaLAN ports, MOS-2220-X1101E for additional printer port, MOS-1110Y-0101E for isolated digital I/O port, MOS-1130Y-0201E for isolated CANBus and so on. All modules pass the EMC and safety certifications and can be factory- or CTOS- or end user-assembled.
Built-in SUSIAccess, Self-sensing, and Smart Remote Management Software
ARK-6322 provides self-sensing and management capabilities for remote monitoring
and control, self-diagnosis and correction with automatic email alerts by Advantech SUSIAccess software support. Acronics executes backup and recovery that can save valuable data in the unlikely event of a system crash. McAfee enhances system security with white-list softare control and also provides an encryption lock to avoid programs being stolen.
Key Features:
- Intel Celeron J1900 quad core 2.0 GHz (burst to 2.41 GHz)
- DDR3L 1333MHz SO-DIMM up to 8 GB
- Dual independent display : VGA + DisplayPort
- Dual Storage Support: 1x 2.5" or 1x 3.5” SATA HDD and mSATA.
- 2 x miniPCIe, one half-size mini PCIe and one full-size shared with mSATA.
- 2 x Intel GbE, 1 x USB3.0, 7 x USB2.0, 6 x COM and 8-bit DIO reserved
- iDoor compatible for customization
- 12V DC with lockable DC jack design
Dimensions: 200 x 200 x 64 mm
Supports SUSIAccess and Embedded Software APIs for self-perception, real-time remote management, security, backup and recovery
OS: WIN8, WIN7, WES7, WES8 and Linux (on a per-project basis) support.
