The First Rule, Encrypt

When implementing a card-based system, protect yourself

It used to be that the most important aspect of implementing an electronic access control system was the simple control of who went where when. Today, the requirements of these sophisticated systems go beyond. Indeed, one of the security challenges frequently heard surrounds denying hackers, cyber-punks and associated bad actors from using the access system as a gateway to an organization’s sensitive IT network.

As an RFID access card gets close to its reader, it begins to wirelessly transmit its binary code. If using 125KHz proximity, then the wireless protocol is typically Wiegand, an older technology that can no longer provide the security needed today. In a worst case scenario, hackers could simply lift that fixed Wiegand clear text, retransmit it to the card reader and, from there, physically enter the facility and thereby the network, allowing these characters free rein to target the IT system.

In fact, the Federal Trade Commission (FTC) has been apprised of so many cyber attacks, and the threat these hacks pose, that it is now holding companies responsible for not implementing good cybersecurity practices. Data encryption is part of good practice and is, indeed, an opportunity for the security industry.

3 Major Elements to Encryption

Authentication. This verifies that someone is who they say they are. Credentials are compared to those on file in a database. When matched, the user is granted access. (“Yes, badge #1234 is in our database. Go ahead.”) Settings are defined by an administrator. For example, in a high security facility, the administrator may demand multifactor authentication, using a card plus PIN.

Integrity. This assures that digital information is uncorrupted and only accessed or modified by those authorized. (“Nobody has messed with this number.”) Data must not be changed in transit or altered by an unauthorized person or program. If data gets corrupted, then redundancies restore the affected data to its original state.

Non-repudiation. This means that users cannot deny the authenticity of their signature on a document or the sending of a message that they originated. (“Nice try but we know that YOU did this.”) A digital signature not only ensures that a message or document has been electronically signed by the person but also ensures that a person cannot later deny they furnished it.

Here is How Encryption Works

Encryption consists of both an algorithm and a key. Once a number is encrypted, the system needs to have a key to decrypt the resultant cyphertext into its original form. There are two varieties of algorithms— private (symmetric) and public (asymmetric).

Private key encryption uses the same key for both encryption and decryption. Be aware—if the key is lost or intercepted, messages may be compromised. Public key infrastructure (PKI) uses two different but mathematically linked keys. One key is private and the other is public.

With PKI, either key can be used for encryption or decryption. When one key is used to encrypt, the other is used to decrypt. The public portion of the key is easily obtained for all users. However, only the receiving party has access to the decryption key allowing messages to be read. Systems may use private encryption to encrypt data transmissions but use public encryption to encrypt and exchange the secret key.

Using one or both these algorithms, access credential communications may be encrypted. Many modern cards support cryptography. Look for terms such as 3DES, AES (which the government uses to protect classified information), TEA and RSA.

Adding Encryption into an Access Control System

If concerned with hacking, consider more secure 13.56 MHz smart cards over 125 KHz proximity cards. Look for the term “Mifare,” a technology from NXP Semiconductors. The newest Mifare standard, DESFire EV1, includes a cryptographic module on the card, adding an additional layer of encryption to the card/reader transaction. DESFire EV1 protection is especially important for customers wanting to use secure multi-application cards for access management, public transportation or closed-loop e-payment.

Another valuable option is Valid ID, an anti-tamper feature for contactless smartcard readers, cards and tags. Embedded, it adds yet an additional layer of authentication and integrity assurance to traditional Mifare smartcards. Valid ID helps verify that sensitive access data programmed to a card or tag is indeed genuine and not counterfeit.

Encrypted Cards and Readers Inhibit Hackers

Whether you need to guard against state sponsored terrorists or the neighborhood teen from hacking the electronic access control systems that you implement, security today starts with encryption. But, that’s just a beginning. To take steps that will further hinder hackers, ask for your manufacturer’s Cybersecurity Vulnerability Checklist.

This article originally appeared in the August 2017 issue of Security Today.
