Sandia National Laboratories Researcher Looks for Bad Guys in Cyberspace
Sandia National Laboratories' computer science researcher Jeremy Wendt wanted to figure out how to recognize potential targets of nefarious emails, and put them on their guard. His goal is to reduce the number of visitors that cyber analysts have to check as possible bad guys among the tens of thousands who search Sandia websites each day.
Ultimately, he wants to be able to spot spear phishing. Phishing is sending an email to thousands of addresses in hopes a few will follow a link and, for example, fall for a scam offering millions of dollars to help a Nigerian prince wire money out of his country. Spear phishing, on the other hand, targets specific email addresses that have something the sender wants.
Wendt has developed algorithms that separate robotic web crawlers from people using browsers. He believes his work will improve security because it allows analysts to look at groups separately.
“Even if an outsider gets into a Sandia machine that doesn’t have much information, that access makes it easier to get into another machine that may have something,” Wendt said. “Spear phishing is scary because as long as you have people using computers, they might be fooled into opening something they shouldn’t.”
Identifying malicious intent
Sandia cyber security’s Roger Suppona said, “The ability to identify the possible intent to send malicious content might enable security experts to raise awareness in a potential target. More importantly, we might be able to provide specifics that would be far more helpful in elevating awareness than would a generic admonition to be suspicious of incoming email or other messages.”
Wendt, in the final stretch of a two-year Early Career Laboratory Directed Research and Development grant, presented his work at a Sandia poster session.
Wendt has looked into behaviors of web crawlers and browsers to see if that matched how computers identify themselves when asking for a webpage. Browsers generally say they can interpret a particular version of HTML — HyperText Markup Language, the main language for displaying webpages — and often give browser and operating system information. Crawlers identify themselves by program name and version number. A small number Wendt labels “nulls” offer no identification, perhaps because the programmer omitted that information or because someone wants to hide. What Wendt was looking for was a computer that didn’t identify itself, or say it’s one thing but behaved like another and trolled websites that the average visitor showed little interest.
Going to an Internet site creates a log of the search. Sandia traffic is evenly divided between web crawlers and browsers. Crawlers tend to go all over; browsers concentrate on one place, such as jobs. Also known as bots, these crawlers are automated and follow links like Google does.
“When we get crawled by a Google bot, we aren’t being crawled by one visitor, we’re being crawled by several hundreds or thousands of different IP addresses,” Wendt said.
Distinguishing bots and browsers
Since Wendt wants to distinguish bots from browsers, without having to trust they’re who they say they are, he looked for ways to measure behavior.
The first measurement deals with the fact that bots try to index a website. When you type in search words, the crawler looks for pages associated with those words, disregarding how they’re arranged on a page. This means a bot pulls down HTML files far more often.
Wendt first looked at HTML downloads. Bots should have a high percentage. Browsers pull down smaller percentages. More than 90 percent of the “nulls” pulled down nothing but HTML — typical bot behavior.
A single measurement wasn’t enough, so Wendt devised a second based on another marker of bot behavior: politeness.
“Bots can suck down webpages from a server so fast it would shut down the server to anyone else,” he said. “That might prompt the site administrator to block them.”
So bots take turns.
“They say, ‘Hey, give me a page,’ then they may crawl a thousand other sites taking one page from each,” Wendt said. “Or, they might just sit there, spinning their wheels for a second, waiting, and then they’ll say, ‘Hey, give me another page.’”
Some behavior is “bursty”
Browsers go after only one page but instantly want all images, code, and layout files for it.
“I call that a burst,” he said. “A browser is ‘bursty;’ a crawler is not ‘bursty.’”
Bursts equal a certain number of visits within a certain number of seconds. Ninety percent of declared bots had no bursts and none had a high burst ratio. Sixty percent of “nulls” also had no bursts, lending credence to Wendt’s identification of them as bots. However, 40 percent showed some “bursty” behavior, making them hard to separate from browsers. However, normal browser behavior also falls within set parameters. When Wendt combined both metrics, most “nulls” fell outside those parameters, leaving browsers that behaved like bots.
“Now, are all these people lying to me? ‘No.’ There could be reasons somebody would fall into this category and still be a browser,” he said. “But it distinctly increases suspicions.”
He also looked at IP addresses.
IP addresses and user agent strings can collide, but Wendt stated that the odds are dramatically lower that two people will collide on the same IP address and user agent string within a short period. That told him they’re probably different people.
Now, he needs to bridge the gap between splitting groups and identifying targets of ill-intentioned emails. He has submitted proposals to further his research after the current funding ends this spring.
“The problem is significant,” Wendt said. “Humans are one of the best avenues for entering a secure network.”
