Achieve compliance without a rip-and-replace investment
- By David Adams
- Oct 01, 2011
When the Homeland Security
(HSPD-12) was enacted in
August 2004, government
agencies embarked on the challenging task of
complying with an evolving set of standards
designed to ensure that all federal employees
and contractors have secure and reliable
forms of identification.
Agencies were given more specific
deadline information in February 2011. The
Department of Homeland Security and the
Office of Management and Budget issued
a memorandum stating that, beginning in
the government’s fiscal 2012—that is, Oct.
1, 2011—all existing physical and logical
access control systems must be upgraded
to implement Personal Identification
Verification (PIV) credentials before
federal agencies can use development
and technology refresh funds to complete
other activities. These access control
systems must use smart card and biometric
technology and support identification
credentials in compliance with National
Institute of Standards and Technology
(NIST) guidelines, which are embodied in
Federal Information Processing Standards
Publication 201 (FIPS-201).
Complying with these guidelines has
generally been a costly and complex process
that has required agencies to gather, organize
and deploy a variety of technologies. Agencies
have also frequently needed to hire experts
and third-party suppliers to assist with their
upgrades and to establish a migration path
from existing credentials. Too often, agencies
have been required to completely replace their
physical access control head-end servers,
panels and door control hardware. With
proper planning and a modular, turnkey
approach, however, FIPS-201 compliance can
be accomplished at a significantly lower cost
while preserving investments in the existing
access control infrastructure.
Compliance Requirements and Deadlines
HSPD-12 is intended to enhance security,
increase government efficiency, reduce
identity fraud and protect personal privacy.
It requires agencies to follow specific
technical standards and business processes
for the issuing and routine use of secure and
reliable forms of identification in compliance
The FIPS-201 document, titled “Personal
Identity Verification (PIV) of Federal
Employees and Contractors,” defines the
multi-factor authentication, digital signature
and encryption capabilities required for
standardized PIV smart card credentials.
Federal employees and contractors must use
these cards to gain access to all government
facilities and disaster response sites. FIPS-
201 compliance is expected to create a
standardized infrastructure of interoperable
access control products across a wide range
of facilities belonging to disparate agencies
and partners. This will lead to reduced overall
costs while improving the government’s
ability to leverage its buying power. All
new systems under development will need
to support PIV credentials and physical
building access modifications according to
One of the most important documents
issued by the government is SP800-
116, which introduces the concept of
controlled, limited and exclusion areas, to
which agencies must tailor risk-based PIV
authentication mechanisms. The document
also proposes a PIV Implementation
Maturity Model (PIMM) to measure
the progress of facility and agency
implementations. Finally, it recommends
to federal agencies an overall strategy for
the implementation of PIV authentication
mechanisms within a facility’s physical
access control system (PACS).
Compliance Best Practices
Using fully interoperable, simple-to-deploy and cost-effective
products and technologies that have been tested and validated as part
of a complete, turnkey solution is the best way to streamline FIPS-
201 compliance. The most successful upgrade programs also provide
agencies with a single point of deployment responsibility, and they
ensure that compliance is achieved quickly, effectively and with all
necessary audit support, on an incremental, pay-as-you-go basis, so
agencies can retain much of their existing infrastructure.
Compliance programs should:
- Enable the authentication of credentials across the full range of
- Deliver compliance without requiring a wholesale rip-andreplacement
of existing equipment;
- Offer the option of implementing a converged physical and logical
security solution as envisioned by HSPD-12;
- Provide a single solution for both FIPS-201 and SP 800-116
- Meet all security, compliance and ROI objectives by enabling the
full range of PIV, PIV-I and CAC card access.
Achieving these objectives requires a modular approach using a new
generation of more flexible and secure reader platforms combined with
modular compliance hardware.
Leveraging Reader Advances for FIPS-201 Compliance
The latest reader technology reduces the complexity of the
compliance process significantly by employing better-protected
architectures that significantly enhance access-control security and
deployment flexibility. These reader platforms employ EAL5+ secure
element hardware that ensures tamper-proof protection of keys and
cryptographic operations. They also use the industry-standard open
supervised device protocol (OSDP) communications standard to
establish a seamless and secure, bidirectional link between the reader
and today’s easy-to-deploy FIPS-201 compliance hardware modules.
Next-generation reader technology also enhances security
by using a new, portable credential methodology on a standardsbased,
technology-independent and flexible identity data structure.
This data structure uses a device-independent data object that HID
Global calls a secure identity object, which can exist on any number
of identity devices. These data objects work with companion SIO
interpreters on the reader side that, together, behave as traditional
cards and readers do while using a significantly more secure, flexible
and extensible data structure.
Device-independent data objects offer three key benefits for
FIPS-201-compliant solutions and other access control system
implementations. First, because they’re portable, these data objects
can reside on traditional contactless credentials and many different
mobile device formats, ensuring interoperability and easy migration.
Second, their device independence enhances trusted security by
enabling them to act as a data wrapper to provide additional key
diversification, authentication and encryption while guarding against
Third, because they use open standards, these deviceindependent
identity objects improve flexibility and can grow in
security capabilities while traditional architectures remain stuck
in a fixed definition. Each of these benefits is critically important
for next-generation, secure identity portability and for enhanced
protection in a FIPS-201-compliant environment.
Implementing a Modular Compliance Upgrade
With a modular upgrade, the only hardware that needs to be added
is new readers, compliance hardware modules and a compliance
manager. Installed between the readers and the existing PACS panel,
the compliance hardware modules are used to validate FIPS-201
cards, extract the badge ID and pass it along to the PACS panel for
an access decision. The compliance manager provides centralized
control of assurance level settings and distribution of validation data.
The most recent offerings add a new service application programming
interface (API) that integrates PACS enrollment capability directly
into the validation service.
Today’s modular compliance systems perform all of the steps
required for PIV authentication. At the time of enrollment, the
trusted card issuers—also known as the trust anchors—are set in the
system. The status of enrolled PIV cards is checked on a periodic basis
to prohibit access by revoked cards. This is done by retrieving the
card revocation status from the issuing certificate authority (OCSP/
CRL/MiniCRL) and the TWIC Hotlist. When a PIV, PIV-I, CAC or
TWIC card with the appropriate assurance level is presented to a
corresponding reader, the compliance hardware module validates the
card according to the assurance level setting, extracts the badge ID
from data on the card, and then passes the badge ID to the PACS panel
for an access decision and logging.
The compliance hardware module also validates PIV cards from
visitors by using the Server-based Certificate Validation Protocol
(SCVP) to implement the path discovery process and establish a
chain of trust through the federal bridge. This enables interoperability
across government agencies and with non-government members of
the federal bridge.
For invalid cards, the compliance hardware module is configurable
to send a preset badge ID to the PACS panel and/or close an output
relay. In case of communication interruption, the compliance
hardware module maintains an updated validation data cache—such
as issuer trust status and revocation status—so it can function offline,
while strong authentication continues at the door.
Additionally, cardholder data can be captured automatically the
first time a card is presented for validation to any reader connected to
a compliance hardware module. The data also can then be stored and
distributed to all other compliance hardware modules by a compliance
management station. This feature delivers several benefits. It allows
traditional cardholder enrollment using existing PACS enrollment
functionality. It also allows integration with an identity management
system or card management system.
Finally, it enables the use of third-party enrollment packages.
Federal agencies face challenges in upgrading their PACS
infrastructure to meet the latest government mandates. Until now,
the compliance process has required multiple vendors, and agencies
have often had to replace their entire systems. A new, modular
hardware approach makes it significantly easier and less costly for
agencies to respond to regulatory changes, while giving them the
flexibility to modify security levels in selected areas, as required, and
take advantage of ongoing advances in access control technology.
