Physical protection of electrical substations is much more critical than simply guarding against copper theft. Recent terrorist attacks on substations and the potential for simultaneous attacks across the United States put the entire country at serious risk for major power interruption. Detection devices such as fence sensors, thermal cameras, microwave and passive infrared (PIR) motion sensors all provide some warning against such attacks but are limited in the ability to detect threats outside the fence line.

For power utility substations, compact surveillance radar (CSR), integrated with PTZ cameras, provides early warning detection and identification of threats both inside and outside the fence line. This is achieved at a price point comparable to fence only solutions and is feasible for electrical utilities.

On April 16, 2013, terrorists attacked a substation near San Jose Calif. A Wall Street Journal article covering the event explained:

“Snipers opened fire on the substation for 10 minutes before a plant operator heard the sound and called 911. The attack continued for another 10 minutes before the attackers slipped into the night, just before police arrived but not before 17 giant transformers were knocked out.”

A recent report from the Federal Energy Regulatory Commission captures the gravity of this and potentially future events like this:

“Destroy nine interconnection substations and a transformer manufacturer and the entire United States grid would be down for at least 18 months, probably longer.”

Until this attack occurred, physical substation security was focused almost exclusively on fence line detection and security of the control house. This attack revealed a critical weakness in this approach as the attackers never entered the substation, but simply shot at transformers from outside the fence as seen in Figure 1. Thus, the attackers were never detected by any of the existing security equipment. The sparks caused by the fence being repeatedly hit triggered the alarm 10 minutes into the shooting. It is evident that outside-the-fence detection and event recording is required to reliably detect and record an attack on a substation.

The Shield System Advantage

A shield system provides reliable outside-the-fence detection and recording of such events. It is a robotic perimeter security system that features CSR integrated with a PTZ Camera (either EO/IR or thermal). The two are integrated through NetworkedIO, a powerful integration platform that applies behavioral filters and automatically slews cameras to the target being tracked by the CSRs. NetworkedIO also allows the user to set parameters to alert operators only when there is activity they are concerned about.

Turnkey shield systems easily integrate into existing security systems as well as operate as standalone systems. Shield systems detect moving people and vehicles over wide areas, cue cameras directly to the intruder, notify an operator of the intrusion in real time, record it and then respond automatically to a threat. In this fashion, Shield provides Robotic perimeter surveillance and deterrence.

There are four levels of Shield packages designed for short, medium, long range and mobile applications.

Among other capabilities, Shield includes automatic, outside-the-fence threat detection with slew-to-cue integration, it is effective operation in rain, snow, sleet, fog, dust and at extreme temperatures and there are lower false alarm rates.

The Shield system adds particular value around large remote substations where detection of an intruder prior to entering the perimeter is critical. In the attack outlined earlier, fence line detectors or cameras looking down the fence line did not detect the event because the attackers never entered the substation or touched the fence. Outside-the-fence detection is required to defend against this type of attack.

Alert zones are configured to alert on any movers that are not on the roads, thus eliminating alerts on normal road traffic. The cameras are positioned to provide complete coverage of the entire perimeter cueing off any of the four radars. Each red ellipse shows the coverage area of one CSR. This configuration provides complete outside-the-fence coverage of the perimeter out to a minimum of 100 meters around the entire perimeter plus significant coverage inside the fence line.

A NetworkedIO device is able to network multiple shield systems and cameras together via any type of TCP/IP network back to an operation center or control room.

The cost of a complete system including all four Shield stations is comparable to the cost of purchase and installation of a fiber based fence detection system for a 3000 feet perimeter. The Shield system would provide complete detection, tracking, recording and alerting of intruders in and around the substation. Recording would only be triggered by events of interest, significantly reducing the amount of space needed to record and time required to review events.

Shield stations are modular in design allowing for site specific layouts and configurations, some of the common devices tied to the Shield are one or more CSRs, PTZ cameras with thermal or IR illumination and NetworkedIO integration platforms.

Security lights trigger on when intruders are detected and loud speakers activate on an intruders’ detection.

Example Installation

One electrical utility company used the Shield System in a yard surrounded by a chain link fence. The yard housed valuable assets and was surrounded by a fence with fiber based vibration detection installed on it. The fiber alarm was frequently set off by trains passing by on the nearby tracks resulting in dozens of daily nuisance alarms.

To resolve the issue a SpotterRF C40 was mounted inside the plant fence line pointed out over the yard and a SpotterRF NetworkedIO CC8A was installed on the same network in a different location. Two alert zones were drawn; one covering the yard with the other covering the interior of the plant itself and filters were applied to minimize nuisance alarms.

The result was that no more alerts were caused by the trains and the utility was able to track intruder movements throughout the yard with cameras cued directly to their locations. Additionally, they had interior coverage to their plant which they did not have with the fiber on the fence.

The advantage of the Shield, for this customer, was a perimeter security solution that was deployed in a few hours, required no trenching, eliminated nuisance alarms caused by trains passing by, and coverage provided inside and outside the fence line from all-weather threat detection with automatic camera cueing.

Electrical Substation Security is critical to the security of any nation. As we have learned from recent terrorist attacks on substations, to effectively secure a substation requires more than just detection of unauthorized entry. It requires detection and protection beyond fences. Proven in military and critical infrastructure environments by companies such as Exxon, Honeywell, and SAIC the SpotterRF Shield System provides the most cost-effective means of providing early warning in remote medium to large scale substations.

This article originally appeared in the February 2015 issue of Security Today.
